Wavelength (nm)

532±1

Operating mode

Q-switched: EOM (Electro-optic modulation)

Single pulse energy (mJ)

30

50

100

150

Pulse duration (ns)

<10

<10

<8

<8

Rep. rate (Hz)

1~10 (adjustable)

Energy stability

<4%

Warm-up time (minutes)

<15

Beam divergence, full angle (mrad)

~1

~1

~1

~1

Beam diameter (mm)

<6

<6

6

7

Beam height from base plate (mm)

75

Cooled method

Water Cooled

Operating temperature (℃)

20~30

Power supply (220/110VAC)

PSU-LPS-S(3U)

Expected lifetime (pulses)

10⁷~10⁸

Warranty period

1 year

Datasheet
