MLL-H-1064

Wavelength (nm)

1064±1

Output power (mW)

>2000, 2600, 2700, … ,3000

Transverse mode

Near TEM₀₀

Operating mode

CW

Power stability (rms, over 4 hours)

<1%, <3%, <5%

Noise of amplitude(rms, 20Hz~20MHz)

<1%

Warm-up time (minutes)

<10

M² factor

<2. 0

Beam divergence, full angle (mrad)

<2. 0

Beam diameter at the aperture (mm)

~3. 0

Beam height from base plate (mm)

29

Polarization ratio

>100:1

Pointing stability after warm-up (mrad)

<0.05

Operating temperature (℃)

10~35

Power supply (90-264VAC)

PSU-H-LED

PSU-H-FDA

PSU-H-OEM

Expected lifetime (hours)

10000

Warranty period

1 year

Datasheet
